Cerit WPP Substation Automation

Country: Turkey, Adiyaman;

End-User: BEST AS;

Project: Cerit Wind Power Plant Substation Automation Project;

Description:154 kV Air Insulated Substation, Capacity 75 MVA, 25 Wind Turbines, 154 kV: 1 Line Feeder, 2 Transformer Feeder, 1 Coupling Feeder, 34.5 kV: 7 Turbine Incoming Feeders, 2 Transformer Feeder, 1 Coupling Feeder;

Scope of works:

• HV Relay Protection and Control Panels, RTU and Communication Panels, LV Distribution Panel;
• HV Relay Configuration and Parameterization;
• All Protection and Control Panels, E-plan Design;
• ABB Relion 650 and 670 Series, Relays and BCU, MV ABB REF615 Relays, MV Siemens 7SJ80 Relays;
• ABB RTU560, IEC101 with TEIAS National Control Center Communication;
• ABB MicroSCADA, HSR System, IEC 61850 Communication;
• Primer and Seconder Equipment, Test, Commissioning and Trainings;
• Wind Monitoring and Forecasting System;
